Hood

Hood
Hood

1. Pull the hood lock release handle 1 located below the instrument panel until the hood springs up slightly.

2. Locate the lever 2 in between the hood and grille and push the lever sideways with your fingertips.

3. Raise the hood 3 .

4. Remove the support rod 4 and insert it into the slot on the underside of the hood 5 .

When closing the hood, return the support rod to its original position, lower the hood to approximately 12 inches (30 cm) above the latch and release it. This allows proper engagement of the hood latch.

● Make sure the hood is completely

● Make sure the hood is completely closed and latched before driving. Failure to do so could cause the hood to fly open and result in an accident.

● If you see steam or smoke coming from the engine compartment, to avoid injury do not open the hood.
