Passenger compartment
Passenger compartment
1. Rear window defroster switch.
2. Interior trunk lid release.
3. Trunk lid.
4. Vehicle loading.
5. Exterior trunk lid release/request button.
6. Replacing bulbs.
7. Fuel-filler cap, fuel recommendation.
8. Fuel-filler door.
9. Child safety rear door locks.
See the page number indicated in parentheses for operating details.
