Nissan Versa: Instruments and controls - Instrument panel

Detailed layout diagram of the Nissan Versa driver cockpit and center console controls showing gauge cluster, steering wheel, and display placement

  1. Air vents (side and center passenger compartment ventilation)
  2. Headlight, fog light (if so equipped), and turn signal indicator control switch
  3. Driver's supplemental front-impact air bag module and integrated horn assembly
  4. Instrument meters and gauges cluster, containing warning and indicator lights, trip computer display (if so equipped), and advanced vehicle information display (if so equipped)
  5. Windshield wiper and washer variable speed switch
  6. Center display control buttons (if so equipped) and steering wheel-mounted audio controls
  7. Front passenger air bag status indicator light and hazard warning flasher switch
  8. Center touch-screen infotainment display
  9. Front passenger's supplemental front-impact air bag module housing
  10. Front passenger's supplemental safety knee airbag
  11. Locking glove box compartment
  12. Climate control adjustment panels and heated seat activation switches (if so equipped)
  13. Gear shift lever (continuously variable transmission or manual transmission)
  14. Push-button ignition switch (if so equipped)
  15. Wireless device charger pad and charging status indicator light (if so equipped)
  16. 12V power outlet, USB connection/data port, and auxiliary (AUX) input jack (if so equipped)
  17. Cruise control switches (if so equipped), Intelligent Cruise Control (ICC) system buttons (if so equipped), and Bluetooth Hands-Free Phone System interface
  18. Driver's supplemental protective knee air bag module
  19. Tilt and telescopic steering wheel adjustment lock lever
  20. Hood release latch and fuel-filler door release pull
  21. Steering wheel switches for audio volume and track control, along with control panel and vehicle information display navigation switches (if so equipped)
  22. Vehicle Dynamic Control (VDC) OFF toggle switch (if so equipped), Enter/select navigation switch for trip computer (if so equipped), Automatic Emergency Braking (AEB) with Pedestrian Detection OFF switch (if so equipped), Rear Sonar System (RSS) OFF switch (if so equipped), and Lane Departure Warning (LDW) system switch (if so equipped)

* For advanced navigation, audio, and configuration details, refer to the separate NissanConnect Owner's Manual (if your Nissan Versa is so equipped).
