Fog light switch (if so equipped)
To turn the fog lights on, turn the headlight switch
to the position, then turn
the fog light
switch to the
position.
To turn the fog lights on with the headlight switch in
the AUTOposition, the headlights must be on, then
turn the fog light switch to the
position.
To turn the fog lights off, turn the fog light switch to the OFF position.
The headlights must be on and the low beams selected for the fog lights to operate. The fog lights automatically turn off when the high beam headlights are selected.
